Magnification |
10x |
Front Lens Diameter (mm) |
42 |
Exit Pupil (mm) |
4.2 |
Twilight Factor |
20.5 |
Field of View at 1,000 yds / 1,000 m |
342 ft / 114 m |
Field of View for Spectacle Wearers |
> 312 ft / > 104 m |
Eye Relief (mm) |
16 |
Objective Angle of View |
6.45° |
Close Distance |
approx. 16 ft / 5 m |
Adjustable Interpupillary Distance (mm) |
56 to 74 |
Diopter Compensation (dpt) |
±4 |
Distance Measurement Range |
10 up to approx. 3,200 yds / 2,950 m |
Equivalent Horizontal Range (EHR) |
10 up to approx. 3,200 yds / 2,950 m |
Correction Output (Applied Ballistics® Ultralight Default Setting) |
max. 875 yds / 800 m |
Correction Output (Applied Ballistics® Elite Upgrade) |
max. 3,200 yds / 2,950 m |
Measuring Accuracy |
±0.5 m at 10-200 m / 0.5 yds at 10-219 yds |
|
±1.0 m at 200-400 m / 1.0 yds at 219-438 yds |
|
±0.5% above 400 m / 438 yds |
Measuring Time |
max. approx. 0.3 sec |
Measuring Modes |
Scanning mode, single measurement |
Switchover Meter/Yards |
Yes |
Ballistic Function |
Yes |
On-board Wind Correction |
Yes |
Applied Ballistics® Ultralight On-board |
Yes |
Bluetooth® Interface |
Yes |
Connect to Leica Ballistics App |
Yes |
Display |
LED display with 4 digits, easily legible in any light |
Eyepiece for Eyeglass Wearers |
Yes |
Eyecups |
Yes, rotary sliding sleeve, detachable, with 4 click-stops |
Prism System |
Perger-Porro system |
Lens Coating |
HDC® multilayer coating, AquaDura® coating |
Focusing |
Internal focusing via central drive |
Laser |
Eye-safe invisible laser according to EN and FDA class 1 |
Laser Beam Divergence |
1.8 x 0.8 mrad |
Barometric Pressure Sensor |
Yes |
Temperature Sensor |
Yes |
Temperature Measurement |
Yes |
Angle Sensor |
Yes |
Compass |
Yes |
Battery |
1 x 3V Lithium-type CR2 |
Battery Lifetime |
Approx. 2,000 measurements at 20°C / 68°F |
Watertightness |
To a depth of 16 ft / 5 m |
Housing |
Magnesium, nitrogen-filled |
Dimensions (W x H x D) |
4.9 x 6.9 x 2.8 in / 125 x 174 x 70 mm |
Weight |
approx. 34.2 oz / 970 g (without battery) |
Accessories |
Winged eyecups (42 006), Floating carrying strap (42163), Tripod adapter (42 220) |
