Holosun IRIS 1 Single-Function Aiming Laser
Key Features
- Three Laser Options – choose a 520nm green, 635nm red, or Class 1 infrared (night-vision) laser to match your platform
- Compact Lightweight Module – redesigned housing is 33% lighter and 20% lower-profile than previous LS117 models
- 7075-T6 Aluminum Housing – hard-anodized aluminum construction provides durability and corrosion resistance in demanding environments
- Integrated Fire Button – top-mounted control supports both momentary and constant-on activation
- Rear Mode Selector Switch – ergonomic rear control allows fast access to power and operating modes
- Remote Activation Switch Included – single-button Crane-plug pressure pad enables flexible weapon-mounted activation
- Precision Adjustments – 0.5 MOA per click with ±50 MOA of windage and elevation travel for accurate zeroing
- AA Battery Powered – runs on a single AA battery with easy front-cap replacement
- IPX8 Waterproof & 1000G Rated – sealed housing protects against water exposure and withstands heavy recoil
Description
The Holosun IRIS 1 is a compact, single-function aiming laser built for lightweight rifle and carbine setups. Available with a 520nm green, 635nm red, or Class 1 infrared laser, its redesigned 7075-T6 aluminum housing is 33% lighter and 20% lower-profile than previous LS117 models — delivering a clean, dependable aiming point whether you're zeroing in daylight or running night vision.
On-board controls include a top-mounted fire button with momentary and constant-on functions plus a rear-facing mode selector, while an included Crane-plug pressure pad allows flexible remote activation. With 0.5 MOA windage and elevation clicks, ±50 MOA of travel, single-AA power, and an IPX8 waterproof, 1000G-rated body, the IRIS 1 is a simple, rugged aiming solution for modern weapon platforms.
Specifications
▼
| FUNCTIONS | |
| Laser Aiming Device | Yes |
| Remote Switch Included | Yes |
| LASER | |
| Green Laser | 520nm · Class 3R · <5mW |
| Red Laser | 635nm · Class 3R · <5mW |
| IR Laser | 800–880nm · Class 1 · <0.7mW |
| Adjustment Per Click | 0.5 MOA |
| W&E Travel Range | ±50 MOA |
| ELECTRONIC | |
| Battery | 1x AA |
| MECHANICAL | |
| Housing Material | 7075 T6 Aluminum |
| Surface Finish | Anodized |
| Housing Color | Black |
| Submersion | IPX8 |
| Vibration | 1000G |
| Working Temperature | -30°C ~ 51°C |
| Storage Temperature | -40°C ~ 70°C |
| PHYSICAL | |
| Dimensions | 3.4″ × 1.6″ × 1.2″ |
| Weight | 4.6 oz |
| Direct Mount | Picatinny |
Package Includes
- ✓IRIS 1 Aiming Laser
- ✓Crane Plug Pressure Pad
- ✓Lens Cloth
- ✓Multi-Tool
- ✓Wrench
- ✓Manual
- ✓Warranty Card
