Key Features
-
4-16x versatile magnification for hunting and precision crossover use
-
First Focal Plane VHR reticle with red illumination
-
AZS zero-stop turrets with precise adjustments
-
Lightweight 30mm tube design for easier carry
-
Side parallax adjustment from 10 yards to infinity
-
Japanese ED glass for improved clarity and contrast
-
Capped windage turret “set and forget” operation
Description
The EP-L (EP Light) is the Light Weight Hunter version of the EP (Extreme Precision) series. It is built on a streamline 30mm main tube to reduce overall weight with our toolless, easy to operate capped windage turret that lets you set and forget. Our Japanese ELD (Extraordinary Low Dispersion) and illuminated VHR (Variable Hunter Reticle) combine to provide astonishing optical performance making this a pleasure for users of all skill levels and disciplines.
Specifications
| Specification |
Details (MIL Variant) |
| Magnification |
4-16x |
| Objective Diameter |
44 mm |
| Eye Relief |
3.6 in |
| Field of View |
30 – 7.5 ft @ 100 yds |
| Tube Size |
30 mm |
| Turret Adjustment |
0.1 MRAD per click |
| Reticle Position |
First Focal Plane (FFP) |
| Reticle Type |
VHR MIL |
| Zero Stop |
AZS Zero Stop System |
| Zero Reset |
Yes |
| Elevation Adjustment Range |
25 MRAD |
| Windage Adjustment Range |
12 MRAD |
| Elevation per Revolution |
8 MRAD |
| Windage per Revolution |
6 MRAD |
| Parallax |
Side focus, 10 yds – Infinity |
| Reticle Illumination |
Red |
| Turret Rotation |
Counter Clockwise (CCW) |
| Length |
13.2 in |
| Weight |
23.7 oz |
| Battery |
CR2032 (Not Included) |
